PWM SWITCHES INACTIVE

terry_b20
Posts: 15
Joined: Wed Nov 28, 2007 10:07 am

PWM SWITCHES INACTIVE

Postby terry_b20 » Wed Nov 28, 2007 12:49 pm

I have installed a Haltech E6x into my nissan Pulsar but i cant get the PWM swithces to function I need to use on of them to control the thermo fan can anyone help with this problem

Regards
terry

User avatar
HaltechScott
Haltech Staff
Posts: 1029
Joined: Wed Sep 26, 2007 10:07 am
Location: Sydney, Australia

Re: PWM SWITCHES INACTIVE

Postby HaltechScott » Wed Nov 28, 2007 4:06 pm

The PWM outputs switch to ground, so you will need to use the PWM to ground the coil of the relay, the other side will need 12v.
Kind Regards
Scott
[email protected] - [email protected]
Ph: +612 9729 0999
Please e-mail support directly for earliest reply.

terry_b20
Posts: 15
Joined: Wed Nov 28, 2007 10:07 am

Re: PWM SWITCHES INACTIVE

Postby terry_b20 » Wed Nov 28, 2007 9:51 pm

I am aware that the pwm switch to ground but when configured ther is no groung signal from the pwm switch

kasmankk
Posts: 29
Joined: Sun Sep 30, 2007 9:45 pm

Re: PWM SWITCHES INACTIVE

Postby kasmankk » Sat Jan 05, 2008 10:49 pm

Hey I have the same problem today, when i tried to use PWM#3 as Engine Control Relay.
It supposed to ONLY switch to ground when it sees RPM, but as soon as i turned on the IG ON, it already switched to ground. Emmmm...i couldn't use this to turn on the relay to the coil to avoid the "pop" when ig is turned on.
Any idea why ?
FordRS FSDE-Turbocharged
E6X Inside

vamian
Posts: 572
Joined: Fri Sep 28, 2007 8:46 am
Location: Greece (Chania-Crete)
Contact:

Re: PWM SWITCHES INACTIVE

Postby vamian » Mon Jan 07, 2008 7:40 am

What fuel mode are you using? I have found that if you use multipoint it will work.
If you use any other fuel mode it doesn’t. Try it and tell us if it’s the same for you too
HALTECH ENGINE MANAGEMENT SYSTEMS
DYNAPACK 2000

kasmankk
Posts: 29
Joined: Sun Sep 30, 2007 9:45 pm

Re: PWM SWITCHES INACTIVE

Postby kasmankk » Sat Jan 12, 2008 11:53 am

multipoint..still the pwm won't work. always on when ig is ON.
could it be the firmware version?
any firmware version update for e6x?
FordRS FSDE-Turbocharged
E6X Inside

bavbim_760il
Posts: 71
Joined: Fri Jan 11, 2008 5:39 pm
Contact:

Re: PWM SWITCHES INACTIVE

Postby bavbim_760il » Fri Feb 08, 2008 5:37 pm

yo kasmank...
I got newest update here...

My car runs pretty well on the Sequential Injc mode.
why don't u try that?

anyway, where have u been?
